Horizontial Splitting Machine

• Place of Origin:

   China

• Type:

  Others

• Genre:

  Machinery & Equipment

• sCode:

  STPR1465752

• Place of Origin:

  Turkey
• 4 DISCS HORIZONTIAL SPLITTING MACHINE (YTYM)
  TECNICAL DATA 4X480
  Total number of disc mm 4
  Disc diameter mm 650-700
  Min/Max cutting width mm 250-480
  Min/Max cutting thickness mm 30-100
  Belt motor power Kw-hp 1,5/2
  Belt width mm 550
  Disc motor power Kw-hp 18,5/25
  Overall dimensions (l-w-h) mm 4520-2400-220

  630 MM 4 DISC HORIZONTIAL SPLITTING MACHINE (YTYM)
  TECNICAL DATA 4x630
  Total number of disc mm 4
  Disc diameter mm 750-850
  Min/Max cutting width mm 250-630
  Min/Max cutting thickness mm 30-100
  Belt motor power Kw-hp 1,5/2
  Belt width mm 550
  Disc motor power Kw-hp 18,5/25
  Overall dimensions (l-w-h.) mm 6700-2400-2200
